Ultimaker S3

Powerful, reliable, versatile 3D printing in a new compact build with an ever growing list of printable materials

Discover the newest edition to the Ultimaker S-Line, the composite-ready, easy-to-use Ultimaker S3 3D printer that delivers accurate, industrial-grade parts, time and again. Based on the winning Ultimaker S5 formula, the S3 also benefits from simple setup, high uptime, and reliable dual extrusion. The Ultimaker S3 is the complete professional 3D printing solution that fits on your average desktop.

Filaments
Accessories
Software
Manual

£4,650.00 (inc. VAT)

Overview

A little bit about the Ultimaker S3

Build Volume

230 x 190 x 200 mm

Precision

X, Y: 6.9 microns (0.069mm), Z: 2.5 microns (0.0025mm)

Layer Height

20 microns (0.02 mm) – 200 micron (0.2m)

Warranty

12 months

Features

Hover on the numbers to see the features

1
2
3
4
5
1

Large Touch Screen Display

A 4.7-inch (11.9 cm) touch display makes operating the 3D printer effortless, displaying visual guides to explain configuration changes and maintenance, plus a visual preview of your print.

2

Build Volume

A build volume of 230 x 190 x 200 mm combined with Ultimaker’s reliable dual extrusion and water-soluble support, gives even more freedom to realize your designs or print multiple parts in one go so you can meet demand with maximum efficiency, while fitting comfortably on your desk.

3

Enhanced Reliability

Active bed leveling ensures a perfect first layer, a closed front controls airflow, and a filament flow sensor will pause your print and notify you if you run out of material. Trust the S5 to do its job while you do yours.

4

Fast Setup, High Uptime

With Ultimaker’s unique print core design, swap nozzles in seconds to switch between build and support materials, or choose from 0.8, 0.4, or 0.25 mm print cores for fast or detailed prints.

5

Designed To Connect

The Ultimaker S5 auto-detects material and print core configuration, while over-the-air firmware upgrades make adding the latest features simple. Print over Wi-Fi, Ethernet, or from a USB stick, and monitor progress via the built-in camera.

Gallery

Take a closer look

Videos

Sit back and enjoy some videos about this 3D printer

View All Our Ultimaker Videos

Please subscribe to the Dream 3D YouTube channel…

Reviews

See what the critics say

the Ultimaker S5 is the ultimate piece of hardware

All3DP

We found the S5 performed flawlessly, producing prints large and small in a variety of materials

Tom’s Guide

our Editors’ Choice as a professional-grade filament-based 3D printer

PC Magazine

Box Contents

Whats included in the box?

  • Fully assembled & tested Ultimaker S3 3D printer
  • 2x AA Print Cores for Nylon, PLA, ABS, CPE
  • 1x BB Print Core for PVA Support Material
  • Cura (which is downloaded here)
  • Power supply, cable and UK plug
  • Two spools of Ultimaker filament
  • USB Stick
  • Ultimaker Phone App
  • Calibration card to level the build plate
  • Glue Stick
  • Grease
  • Hex Wrenches

Specification

Lets get down to detail

Printer and Printing Properties
TechnologyFused Filament Fabrication
Print headDual-extrusion print head with an auto-nozzle lifting system and swappable print cores
Build volumeXYZ: 230 x 190 x 200 mm (9 x 7.4 x 7.9 inches)
(left or right nozzle, or dual extrusion)
Filament diameter2.85 mm
Layer resolution0.25 mm nozzle: 150 – 60 micron
0.4 mm nozzle: 200 – 20 micron
0.8 mm nozzle: 600 – 20 micron
Step accuracy X, Y, Z6.9, 6.9, 2.5 micron
Build speedLess than 24mm3/s
Build plateHeated glass build plate (20 – 140 °C)
Material typesPLA, TOUGH PLA, PVA, ABS, CPE, Nylon, PC, CPE, PP, CPE+, DSM Arnitel ID 2060 HT, Ultimaker TPU 95A, DuPont™ Hytrel® 3D4100FL
Reinforced composites : Owens Corning XSTRAND™ GF30-PA6, DSM Novamid® ID1030 CF10
Support Materials: Ultimaker PVA , Ultimaker Breakaway
Build plate temperature(20 – 140 °C)
Build plate levelingActive leveling
Supported materialsOptimized for: PLA, Tough PLA, Nylon, ABS, CPE, CPE+, PC,
TPU 95A, PP, PVA, Breakaway
Also supports third-party materials
Nozzle diameter0.25 mm, 0.4 mm, 0.6mm, 0.8 mm
Nozzle temperature180 – 280 °C
Nozzle heat up timeLess than 2mins
Build plate heat up timeLess than 4 mins (from 20 to 60 °C)
Operating sound50 dBA
Power rating500 W
Material recognitionAuto-recognition with NFC scanner
ConnectivityWi-Fi, LAN, USB port
Display4.7-inch (11.9 cm) color touchscreen
Language supportEnglish, Dutch, French, German, Italian, Japanese, Korean,
Portugese, Russian, Spanish, Simplified Chinese
MonitoringLive camera (view from desktop or app)
Physical Dimensions
Dimensions394 x 489 x 637 mm
Dimensions (with bowden tubes
and spool holder)		394 x 489 x 637 mm
Net weight 14.4 kg (31.7 lbs)
Shipping weight15.5 kg
Shipping box dimensions400 x 395 x 590 mm
Ambient conditions
Operating ambient temperature15 – 32 °C, 10 – 90% RH non-condensing
Non-operating temperature0 – 32 °C
Software
Supplied softwareUltimaker Cura, our free print preparation software
Cura Connect, our free printer management solution
Supported OSMacOS, Windows and Linux
Plugin integrationSolidWorks, Siemens NX
File typesUltimaker Cura: STL, OBJ, X3D, 3MF, BMP, GIF, JPG, PNG
Printable formats: G, GCODE, GCODE.gz, UPF
Warranty and service
Warranty period12 months
Technical supportLifetime support from Ultimaker’s global network of certified
service partners
