RAISE3D PRO2 PLUS

£3,600.00 (excl. VAT)

High specification, dual extrusion Large 3D printer

Competitive and scaleable; the Raise 3D Pro2 Plus 3D printer improves upon its award winning predecessor and provides the next generation of performance.



Please scroll down to find full product specs, features, videos and more 👇



£3,600.00 (excl. VAT)

Availability: 2 in stock

£3,600.00 (excl. VAT)

Need help? info@dream3d.co.uk / 02070888163

Availability: 2 in stock

or

RAISE3D PRO2 PLUS

0
£3,600.00 (excl. VAT)

Ongoing Tech Support

Thousands of products available for next day delivery

We accept:

Product Details

Pictures & Videos

Buying Options

Product details

Electronic Driven Dual Extrusion with Retracting Hot Ends

Prints complex mechanical parts, supports a variety of multi-material filaments and improves print speed.

  • High repeatability (<0.005mm, 5 micron)
  • Lightning speed (<1 second switching time)
  • 1.5mm lifting distance, compatible with flexible filaments
  • High reliability (tested >100,000 times)

Intuitive User Experience

  • 7-inch Touch Screen
  • Visual interface / Rapid reviewing / Visual print progress / Full adjustment control



Next Generation Motion Controller

Best in class reliability / Precise voltage control / Silky smooth movement / Superior thermal performance

  • 400MHz ARM Cortex-M7 32bit RISC FPU
  • Industrial grade components
  • Stand-alone motor driver
  • 256 micro-steps driver system



New Extruder with Filament Run-out Sensor

Effortless, Dependable and Accurate with optical run-out sensors and end stops

  • Better grip: Dual gear driven
  • No slipping: 4× increased torque performance
  • Worry free prints: Optical run-out sensor



New Extruder with Filament Run-out Sensor

Effortless, Dependable and Accurate with optical run-out sensors and end stops

  • Better grip: Dual gear driven
  • No slipping: 4× increased torque performance
  • Worry free prints: Optical run-out sensor



Build Plate System

Excellent warping prevention / Even heat distribution / Longer lifetime / Easy to remove

  • Aerospace grade material
  • High temperature silicone heating bed
  • Magnetically-held aluminium bed
  • Improved 4+9 points lock system



Box Contents

Whats included in the box?

  • Fully Assembled & Calibrated Raise3D Pro2 Plus
  • 2 Spools of Filament
  • BuildTak Sheet
  • UK Power Supply
  • Scraper
  • USB Stick
  • Set of Allen Keys

Specification

Printer

PRINT TECHNOLOGY FFF
BUILD VOLUME (WXDXH) 12x12x24 inch / 305x305x605 mm
LAYER RESOLUTION 0.05-0.25 mm
FILAMENT TYPE PLA/ PLA+/ ABS/ PC/ PETG/ R-flex/ TPU/HIPS/ Bronze-filled/ Wood-filled
BUILD PLATE Heated Aluminum Build Plate with Magnetic Holding
HEATED BUILD PLATFORM Yes
MAX BUILD PLATE TEMPERATURE 110°C
ENCLOSURE Yes
NOZZLE DIAMETER 0.4 mm (0.016 in)
NOZZLE WORKING TEMPERATURE 170-300 ℃
NUMBER OF NOZZLES 2
PRINTING SPEED 10 – 150 mm/s
MOVING SPEED 150 – 300 mm/s
POSITIONING ACCURACY XY-axes: 0.0125 mm, Z-axis: 0.00125 mm
SLICING SOFTWARE ideaMaker, Simplify3D
SUPPORTED FILE TYPES .stl, .obj
SUPPORTED OS Windows XP and later versions, Mac, Linux
MACHINE CODE TYPE gcode
USER INTERFACE 7 inch capacitive touch-screen
SCREEN RESOLUTION 1024*600
MOTION CONTROLLER ATmega2560
LOGIC CONTROLLER Freescale imx6, Quad core 1Ghz ARM processor
MEMORY 1GB
ONBOARD FLASH 8GB
OS Embedded Linux
PORTS Sdcard*1, Usb2.0*4, Ethernet*1
EXTENDABLE PORTS PWM*2, I2C*1, SPI*1, UART*1, GPIO*4, 8Bit ADC*5, USB2.0*1, 5v-1A*2, 3.3v-200mA*1, Reset*1, Gnd*3
NETWORK Ethernet, 802.11b/g/n Wifi

Construction

FRAME Aluminum
ENCLOSURE ABS, Acrylic and Polycarbonate
MACHINE SIZE (WXDXH) 24.3×23.2×29.9 inch / 616x590x760 mm

Electrical

POWER SUPPLY INPUT Universal 100-240 VAC, 50/60 Hz
POWER SUPPLY OUTPUT 600 Watts, 24 VDC

Raise3D Verified Materials

R3D premium
R3D colorful
PolyMaker: all filaments
Esun: PLA, ePC, Flex, PETG, ABS, Elastic, Particle-filled PLA
Filament CA: ABS, HIPS, Flex, PETG, TPU
NinjiaFlex
Colorfab: all PLA/PHA
Zortrax: all filaments

Customer Verified Materials

Taulman: T-glass, Alloy910
EUMaker: PLA
Wanhao: PLA
ECO: ABS
3D2print: ABS
Makerbot: PLA
Hobbyking: PLA, Bronzefill, POM
